Happymodel ES24TX Pro Micro ExpressLRS 1W ELRS module


The Happymodel ES24TX Pro Micro ExpressLRS TX module is an upgraded version of the ES24TX module.

The ES24TX Pro comes with improvements over the original. Max output power now up to 1000mw, reserved cooling fan, and an RGB LED module. This Micro TX module supports most OpenTX radio transmitters with Micro JR bay. And this time the ES24TX Pro module comes completely assembled before out of the factory.

Login to view prices

The ES24TX Pro Micro ExpressLRS TX module is an upgraded version of the ES24TX module.

The ES24TX Pro comes with improvements over the original. Max output power now up to 1000mw, reserved cooling fan, and an RGB LED module. This Micro TX module supports most OpenTX radio transmitters with Micro JR bay. And this time the ES24TX Pro module comes completely assembled before out of the factory.

Specifications of Happymodel ES24TX Pro

  • Regulatory Domain: ISM2400
  • MCU:ESP32(main),ESP8285(aux,as espbackpack)
  • RF chip: SX1281IMLTRT
  • JR standard 5pin socket
  • Frequency Range: 2400 MHz to 2500 MHz
  • Maximum receive refresh rate: 500Hz
  • Minimum receiver refresh rate: 25Hz
  • RF Output Power: >30dBm
  • Power supply voltage: 5v~10v
  • Weight: 51gram(without antenna)
  • Dimension: 70mm*49mm*32.5mm
  • Antenna gain: 4.18dBi
  • Firmware target: HappyModel_ES24TX_Pro_Series_2400_TX

Includes

  • ES24TX Pro Micro TX module *1
  • Happymodel 2.4GHz Moxon antenna *1

Click here to know more about this product from Happymodel.
