5" Frames, 6"+ Frames, Frames
Mark4-HD Mark4 HD Mark 5inch 224mm / 6inch 260mm / 7inch 295mm FPV Racing Drone Quadcopter Freestyle Frame For XL5 / APEX Frame
Login to view prices
Name: REA-Mark4 HD5
Propeller: 5 inch
Weight: 121g
Motor to moto: 224MM
Size: 138*176MM
Arms plate: 5MM
Top plate: 2.5MM
Bottom plate: 2.5MM
Side plate: 2. 5MM
Recommended configuration:
Flight Controller: RF/Kiss/F3/F4/F7
Motors: 2205 /2206/2207/2305/2306
ESC: 30A-50A
Propeller: 5 inch
FPV: DI FPV Air Unit
Battery: 4S 1500mAh-6s 11 50mAhM3x10 M3x10M3x10
M3x14M3x12 Button ScrewButton ScrewM3x14Button ScrewFlat ScrewFlat ScrewButton Screw
Assembly Schematic:
Name: REA-Mark4 HD6
Propeller: 6 inch
Weight: 131g
Motor to moto: 260MM
Size: 162*203MM
Arms plate: 5MM
Top plate: 2.5MM
Bottom plate: 2.5MM
Side plate: 2.5MM
Recommended configuration:
Flight Controller: RF/Kiss/F3/F4/F7
Motors: 2207/2305/2306/2407
ESC: 35A-60A
Propeller: 6 inch
Battery: 4S 1500mAh-6s 1300mAh
FPV: DJI FPV Air Unit
Name: REA-Mark4 HD7
Propeller: 7 inch
Weight: 141g
Motor to moto: 295MM
Size: 193*223MM
Arms plate: 5MM
Top plate: 2.5MM
Bottom plate: 2.5MM
Side plate: 2.5MM
Recommended configuration:
Flight Controller: RF/Kiss/F3/F4/F7
Motors: 2305/2306/2407/2408/2507
ESC: 40A-60A
Propeller: 7 inch
Battery: 4S 1800mAh-6s 2200mAh
1Set x Mark4-HD5 5inch 224mm / Mark4-HD6 6inch 260mm / Mark4-HD7 7inch 295mm ( send as your choice)
1pcs x battery belt
| Weight | 0.15 kg |
|---|---|
| Propeller | 5inch, 6inch, 7inch |
