Flywing FW450 V2 RC 6CH 3D FW450L GPS Intelligent Helicopter


Flywing Fw450 V2 will be the Most performing and stable Flybarless Helicopter that has a GPS in an affordable price point!

Login to view prices

Flywing Fw450 V2 will be the Most performing and stable Flybarless Helicopter that has a GPS in an affordable price point! Flywing Fw450 V2 is equipped with a 16V high-power motor, which is easy to carry and maintain with the quick dismantling tail tube design; with H1 flight control with omni-GPS positioning technology, it can realize forward / backward hovering at fixed points and intelligent return After GPS positioning, you can switch to GPS mode at any time to save the helicopter by using 3D stunt mode.

Hover at a fixed point, beginner can operate

In the GPS mode, go with push rod, stop with release rod The addition of fixed height function can make the plane always maintain the height, so that players can focus more on flying, beginner can also operate it.





Robust flight control

The function of air pressure height setting + dual-mode GPS fixed-point, the helicopter run with push, stop with a release so that the beginner can start quickly. Thanks to Omni-GPS positioning technology, the helicopter can invert-hover by one key,and cooperate with the rescue function, making 3D practice easier. There is also an automatic route mode for training routes.



The same FBL rotor  structure as class 700

The high-precision FBL rotor structure can make the hand feel more round and thick. Compared with the traditional 450L DFC structure, the addition of the swing hinge makes the flight more stable. The size of the horizontal axis of the main shaft is also 470L, which is sturdy and durable.



Metal gears,solid anddurable

Fw450l adopts all metal big gear design, with high strength industrial m3 arc drive belt, which is solid and durable. Simple maintenance, with torsion spring pressure pulley, without tools, can be replaced by hand for one min! The traditional helicopter to replace plastic gear, need a variety of types of screwdriver tools with the use of the first disassembly of the aircraft spindle, in order to take out the transmission group, and then dismantle and replace the big gear,the process is complex, time-consuming and laborious, novice maintenance is difficult.



16V power, powerful and efficient

The 2816 large brushless motor driven by 16V higher voltage has higher power and higher efficiency than the2221 motor of 12V voltage used by other traditional 450L motors.It’s equipped with 32-bit dual-processing 16V 60A all metal helicopter special electric adjustment, which enables the helicopter to maintain super fast response ability in the fierce 3D flight. Excellent constant speed effect enables the whole flight process to maintain consistent power output without turning.







Quick disassembly, easy to carry and maintain

The tail tube can be easily pulled out and put into the backpack by gently rotating the red board machine. The modular design is also convenient for maintenance, and the addition of 22mm metal rectangular liner makes it more durable.







One key return, low voltage return

When the helicopter loses its way, it will automatically return to the take-off point when the HOME switch is turned or the voltage is low. When the transmitter is lost, the helicopter will automatically return to the take-off point. Midway through the mode switch, cancel the return.



One key to invert fly in Flywing FW450 V2, beginner can fly acrobatics

Depending on the omni-GPS positioning, the invert flight can also hover at a fixed point. If the invert flight switch is turned from normal flight to invert flight, the helicopter will auto roll into invert flight and hover at a fixed point. You can also use 3D manual mode to roll and dial GPS to realize fixed-point invert flight.



3D acrobatic, one key to home

When 3D manual flight, the helicopter automatically increases the speed to ensure the flight power. It can switch to GPS mode at any time, and the helicopter will auto hover stably to achieve the function of one key rescue. Thanks to omni-GPS positioning,the helicopter can fly invert to save the helicopter. When the helicopter approaches the angle of invert flight, the helicopter will keep flying backward and fix the height at a fixed point, so the rescue is faster and safer without overturning.



One click route, easy to learn route flight

With a flick of the switch, the helicopter can start to auto circle or 8-word flight; at this time, you can learn the route by observing the flight posture of the helicopter; you can also control the direction key to spin the route.





Details



FBL Flybarless Main Rotor

Used with class 700 aircraft FBL rotor head group, high stability, Join the swing hinge,the Helicopter is more stable and easy to operate.



Carbon fiber main frame

Aviation grade high-strength carbon-fiber material main frame strong anti twist, can be competent for high-intensity violent flight.



High performance Brushless tail motor

Custom brushless tail motor with special helicopter ESC program Strong tail locking performance, fast response, 22mm metal tailtube More durable.



Flywing FW450 V2 has metal 60A ESC,

60A dual output two in one ESC, Using helicopter specific procedures,support for constant speed and slow start,The flight is more stable and efficient.



Widen the landing skid

High toughness foot, not easy to break.Widened design, more stable takeoff and landing Yes, it’s not easy to roll.



Flywing FW450 V2 has Metal Main Shaft Bearing Block

Metal servo seat, solid and stable.With metal gear helicopter servo, high performance, strong torque, make the flight action fast and accurate



Metal fixed seat, durable, with good heat dissipation, bright cutting surface, exquisite and beautiful.
Specification:
Brand: FLY WING
Product: Flywing FW450 V2 RC Helicopter
Channel: 6CH
Battery: 4S 52WH Battery
Body Length: 880mm
Body Width: 110mm
Body Height: 220mm
Main Rotor Diameter: 800mm
Main Blade Length: 360mm
Tail Rotor Diameter: 127mm
Motor Gear: 11T
Drive Gear: 66T
Tail Drive: Brushless Motor
Weight(no battery): 800g
Flight Time: apporx. 15mins
Flight Distance: apporx. 1000m
Features:
– 6CH, FBL 3D Flying design.
– With Newest H1 flight control system, support GPS and altitude hover flight.
– Support one-key return function, the flying trace looks like number “8”.
– With 4S 2200mAh large capacity battery, flying time is up to 15mins(approx), and the flight distance up to 1000m.
– Using 700 class helicopter all-metal rotor, brushless 5mm shaft tail motor, high speed and sensitive response_.
– All-metal main gear, 18mm 3k carbon fiber tail boom, with 2816 poweful brushless main motor.
– Transmitter can be changed to mode 1 /mode 2 freely.
User Manual for Flywing FW450 V2: Click here
Click here to download the firmware files for the Flywing H1 flight controller. Check out our other Helicopters here.
Package:
1* FLY WING FW450 RC Helicopter
1* 10CH Flysky Transmitter
1* 4S 4450mAh Lipo Battery
