EV800D 5.8G 40CH Diversity FPV Goggles 5 Inch 800*480 Video Headset HD DVR Build in Battery


Login to view prices

EV800D Goggle:



Features:

  • With DVR, you can record videos anytime and anywhere;
  • Low power consumption;
  • Diversity module reception to make the signal more stable;
  • Auto-Searching, support a key search frequency;
  • 5 Inch 800*480 dot high brightness LCD screen;
  • Built-in super sensitiveness 5.8GHz 40ch receiver, especially with RaceBand;
  • Built-in 7.4V/1430mAh high-capacity Li-ion polymer Battery;
  • Universal DC055 charging interface;
  • Real-time video return, Very low time-delay;
  • The menu supports 8 languages;
  • Support external video signal input;
  • Support Audio signal output (You can connect headphones)

Description :

Model
Name 5.8G FPV Goggles
LCD Screen Screen size:    5 Inch
Resolution:    800*480
Display Ratio:  16:9
View Angle:    6 o’clock
Brightness:    300cd/m² with high brightness backlight LED
Video delay Video time-delay less than 20ms
Lens 2.8X Fresnel Lens, 92% transparent rate no distort of light
Interface Antenna 2 X RP-SMA male
DC055 To charge the battery
AV Jack External video signals input or internal Audio signal output
Card slot TF-Card, Support up to 32G(C10 recommend)
DVR REC size:    VGA / D1 / HD               Selectable
REC sound:  ON / OFF                   Selectable
REC time:   OFF / 3min / 5min / 10min     Selectable
Frame rate:  30 Frames
Compress format:  MJPEG
Record file format:  AVI
Languages English,German,French,Spanish,Italian,Chinese,Russian,Japanese
Power

Supply

Power adapter:  DC12V/2A (DC055 interface)
Battery:  7.4V/1430mAh,

DVR module ON: Each full charge revive around 2.5hr working time

DVR module OFF: Each full charge revive around 3.5hr working time

Power Consumption:

* Normal mode: The device operating current of 400mA at 3.7V;

* Record Mode : The device operating current of 620mA at 3.7V;

* Built-in battery maximum charge current of 800mA;

Wireless Frequency Table(MHz)
CH1 CH2 CH3 CH4 CH5 CH6 CH7 CH8
Band A 5865 5845 5825 5805 5785 5765 5745 5725
Band B 5733 5752 5771 5790 5809 5828 5847 5866
Band E 5705 5685 5665 5645 5885 5905 5925 5945
Band F 5740 5760 5780 5800 5820 5840 5860 5880
Band R 5658 5695 5732 5769 5806 5843 5880 5917
Body Dimension:  180mm * 140mm * 84mm
Weight:     410g(with headband, not included antennas)



Note: Cannot record video input from AV port.
