iFlight XING X1404 1404 3800KV 4600KV 3-4S Brushless Motor for DC2 HD TurboBee 160RS Toothpick RC Drone FPV Racing

Availability:

Out of stock
Add to wishlist
Compare

$15.99 $17.99

Compare

Specification:
Brand Name: iFlight
Model: XING X1404
Item Name: 1404 3800KV 4600KV 3-4S Brushless Motor

Input Voltage: 3-4S
Optional KV: 3600KV/4600KV ( Optional)
Quantity: 1 PC
Version: CW Screw Thread
Configuration: 9N12P
Stator Diameter: 14mm
Stator Length: 4mm
Shaft Diameter: 1.5mm
Motor Dimensions(Dia.*Len): Φ19.2×18.5mm
Max Current(60S): 13.58A@3800KV; 12.08A @ 4600KV
Max Continuous Power(60S): 217.3W@3800KV; 193.3W@ 4600KV
Internal resistance: 145mΩ@3800KV;  175mΩ@ 4600KV
Idle Current(10)@5.5V: 0.85A@3800KV;  0.55A@ 4600KV
Weight: 9.3g
Bearing Size: 5x2x2.5mm
Application: 4600KV Version is original replace motor for iFlight DC2 HD FPV Racing Drone,
Package Included:
1x 1404 Motor
1x M2x5 mounting screws
