Holybro 433Mhz 915Mhz 500mW Transceiver Radio Telemetry Set V3 for PIXHawk 4 Flight Controller
(the range can be extended to several kilometers with the use of a patch antenna on the ground).
The radio uses open source firmware which has been specially designed to work well with MAVLink packets
and to be integrated with the Mission Planner, Copter,Rover, and Plane.Specification: (Manual)
Brand Name: Holybro
Version: 433Mhz / 915Mhz ( Optional)
Item Name: 500mW Transceiver Radio Telemetry Set V3
Application: Compatible for Pixhawk 4 Flight Controller
Size: 26 x 53 x 10.7mm (without antenna)
– Open-source SIK firmware
FT230X is a USB to BASIC UART IC
– Serial interface: 3.3 V UART
– Red LED solid – in firmware update mode
(“Telem 2” can also be used but the default recommendation is “Telem1”).
(which should have been included with the radio) to your PC.The necessary drivers should be installed automatically and the radio will appear as a new “USB Serial Port”
in the Windows Device Manager under Ports (COM & LPT).
The Mission Planner’s COM Port selection drop-down should also contain the same new COM port.
2x 433Mhz OR 915Mhz Radio Module with antenna
