1、Mechanical Specification:
Size:55X20X38
Limit Angle:No limit
Case material:PA+Aluminum
Gear material:Metal Gear
Bearing type:Ball bearings
Angle Sansor:Carbon-Film Potentiometer
Angle:220°
Life:1000000Cycles Min
Connector and Cable:Type:JR
Material:PVC
Length:30CM
“Pin Definition:1 Signal
2 Vcc
3 GND”
The Weight:65± 1g
Horn Type:25T/5.9mm
Gear Ratio:1/356
Back Lash:≦0.5°
The rocker phantom:0°
The rocker screw:M3X6
Motor:CoreLess Motor
2、Control Specification:
Command Signal:Pulse width modification
Control System Type:Digital comparator
Operating Travel:180°
(at 500→2500μsec)
Left&Right Travelling Angledeviation:≤ 5°
Centering Deviation:≦1°
Neutral Position:1500 μsec
Dead Band Width:≤4 μsec
Rotating Direction:Counterclockwise(在1500→2000 μsec)
Pulse Width Range:500→2500 μsec
Electronic Protection:Stall 3sec
3、Package Include:
1 X Feetech Fi7635M Digital Servo
![FZ4578A (1)](https://ae01.alicdn.com/kf/He19994c3b0f64587a44a1679ad15c2a8N.jpg)
![FZ4578A (4)](https://ae01.alicdn.com/kf/Hbe969a26d8bb425d84e7e1534d653954Q.jpg)
![FZ4578A (3)](https://ae01.alicdn.com/kf/He8f1ac9ad8d34968be3cec8901c381fct.jpg)
