DJI O3 Air Unit Camera Module

Availability:

In Stock


$109.00 $113.00

In Stock

About this product

The DJI O3 Air Unit Camera Module is a single camera module with a quick-release design for convenient replacement. This camera module features a 1/1.7-Inch CMOS sensor, 155° Super-Wide FOV, f/2.8 aperture, and more!

Compatible with the DJI O3 Air Unit Transmission Module and works with DJI FPV Goggles V2, DJI Goggles 2, and DJI FPV Remote Controller 2.

Features

  • Works with DJI FPV Goggles V2, DJI Goggles 2, and DJI FPV Remote Controller 2
  • 155° Super-Wide FOV
  • 1/1.7-Inch CMOS Sensor
  • Compact in Size
  • Compatibility: DJI O3 Air Unit Transmission Module

Specifications

  • Camera Sensor
    • 1/1.7-inch CMOS
    • Effective Pixels: 48 MP
  • Camera Lens
    • FOV: 155°
    • Equivalent Focal Length: 12.7 mm
    • Focal Length: 2.34 mm
    • Aperture: f/2.8
    • Focus Mode: FF
    • Focus Range: 0.6 m to ∞
  • Camera ISO Range
    • 100-6400 (Auto)
    • 100-25600 (Manual)
  • Camera Shutter
    • Rolling Shutter
  • Camera FOV: 155°
    • Camera Video Resolution
    • With DJI Goggles 2:
      • 4K@50/60fps
      • 2.7K@50/60/100fps
      • 1080p@50/60/100fps
    • With DJI FPV Goggles V2:
      • 4K@50/60fps
      • 2.7K@50/60/100/120fps
      • 1080p@50/60/100/120fps
  • Effective Pixels: 48 MP
  • Video Format: MP4
  • Weight: Approx. 8.3 g (coaxial cable included)
  • Dimensions (L×W×H): 21.2×20×19.5 mm
  • Weight (coaxial cable included): Approx. 8.3 g
  • Coaxial Cable Length: 115 mm

IMPORTANT NOTES

  • The 155° FOV is only available when using the 4:3 aspect ratio, and when the video recording specification is at 2.7K@50/60fps or 1080p@50fps/60fps; the aspect ratio is 16:9, and the video recording specification is at 4K@50/60fps, 2.7K@50/60fps, or 1080p@50/60fps.
  • Video latency data varies depending on the headset you use. With DJI Goggles 2 at 1080p/100fps video transmission quality, the lowest latency is 30ms. With DJI FPV Goggles V2, at 810p/120fps video transmission quality, the latency does not exceed 28 ms.
  • Compared to using DJI FPV Goggles V2 and DJI FPV Remote Controller.4K/60fps videos do not support the aspect ratio of 4:3, and only support that of 16:9.
  • This device is compatible with DJI Goggles 2, DJI FPV Goggles V2, and DJI FPV Remote Controller 2.
  • 4K/60FPS videos only support 16:9 aspect ratio. A 4:3 aspect ratio is not supported.

Includes

  • 1x DJI O3 Air Unit Camera
  • 1x Coaxial Cable
  • 4 M2 Screws
