Caddx Polar Vista Kit Starlight Digital HD FPV System 720p/60fps Low Latency 5.8GHz FPV Transmitter + F/1.6 FOV 162° FPV Camera For DJI Digital Goggles

Availability:

Out of stock


$159.00 $169.00

Specifications:

Brand Name: Caddx

Item Name: Polar Vista Kit

Weight: Vista Kit(camera included): 28g; Antenna: 1.5g

Dimensions: Vista Kit: 30x29x13mm; Camera: 19x19x24mm; Coaxial Cable: 120mm

Operating Frequency: 5.725-5.850GHz

Transmitter Power(EIRP): FCC/SRRC/MIC: <30dBm; CE: <14dBm

Min.latency(end-to-end): 720p 60fps: <32ms

Max.Transmission Distance: FCC/SRRC: 4km; CE: 0.7km

I/0 Interface: USB-C,IPEX,3-in-1port

Supported Flight control System: F3.F4.F7

Operating Temperature Range: 32° to 104°F (0° to 40°C)

Input Power: 7.4-26.4V

Power 0utput: 25mW/200mW/500mW/700mW

Hardware Included: Polar Vista Kit / M2 Screw / Gasket Ring Menu Cable / 3-in-1 Cable / Coaxial-cable / antenna

Compatible Goggles: Work with DJI goggles

Camera Specifications:

Color: Silver, Brown (optional)

Sensor: 1/1.8″ Starlight CMOS

Min. Illumination: 0.00003Lux

Lens: F/1.6 & 8 Mega

Shutter: Rolling shutter

ISO: 100-25600

FOV: 162°(D);138°(H);75°(V)

Aspect Ratio: 16:9

Features:
– 1/1.8 inch HD digital starlight sensor, 0.00003Lux illumination.
– 32ms/4km low latency HD image transmission.
– 720p/60fps video recorded by the DJI FPV Goggles.
– Security chip,compatible with the upgraded version of Vista.
– Allow up to eight drones to fly simultaneously.
– Support brightness and saturation adjustment.

Package Included:
1x Polar Vista Kit

6x M2 Screws 3/4/5mm

4x Gasket Ring

1x 3-in-1 Cable

1x Menu Cable
