BrotherHobby LA 2005 1450/2800 6S 2450/3450KV 4S Ultralight Brushless Motor for RC Drone FPV Racing

Availability:

In Stock


$19.89 $20.89

Features:

1.Designed for flower flying,challenge the limit,see the future,to help you control every movement.

2.TC4 titanium alloy hollow shaft is used High strength,More toughness and impact resistance

3.N52h arc magnet and TU1 oxygen free enameled wire are used micro air grap,low magnetic energy loss

4.Imported NMB bearing configuration,longer service life Free and quiet



5.High temperature resistant enameled wire,Support full throttle violent flight for a long time.

Description:

Brand: Brotherhobby

Item Name: LA 2005 Ultralight Motor

KV: 1450/2450/2800/3450KV(Optional)

Base casing: Al 7075

Stator: 0.15mm Nippon Steel silicon steel

Configuration: 12N14P

Prop Adapter Shaft Thread: M5

Shaft: SUS 420

No.of Cells(Lipo): 4-6S

Bolt Pattern: M2 (12X12mm)

Bearings: Japanese NMB 7x3x3mm

Weight: 21.01g with 16cm SR wires

Wire AWG: 24AWG 16cm length

Bell cap: Al 7075

3450KV

KV: 3450KV

Stator Dimension(mm): 20

Stator Height(mm): 5

AWG: 24# 160mm Length

Motor Dimension(mm): Φ24.6×26.9

Weight Including Cable(g): 21.01

Magnet: N52H

Internal Resistance(mΩ): 67.59

Idle Current@8V(A): 1.5

No.of Cells(Lipo): 4S

ESC: 4S 24A

Max power(W): 367.29

Propeller: 3in Triblade

Max Current(A): 23.10

Hipot test@500V AC: PASS

Dynamic: ≤6mg

2800KV

KV: 2800KV

Stator Dimension(mm): 20

Stator Height(mm): 5

AWG: 24# 160mm Length

Motor Dimension(mm): Φ24.6×26.9

Weight Including Cable(g): 21.07

Magnet: N52H

Internal Resistance(mΩ): 84.57

Idle Current@8V(A): 1.2

No.of Cells(Lipo): 6S

ESC: 6S 27A

Max power(W): 623.79

Propeller: 3in Triblade

Max Current(A): 26.10

Hipot test@500V AC: PASS

Dynamic: ≤6mg

2450KV

KV: 2450KV

Stator Dimension(mm): 20

Stator Height(mm): 5

AWG: 24# 160mm Length

Motor Dimension(mm): Φ24.6×26.9

Weight Including Cable(g): 20.77

Magnet: N52H

Internal Resistance(mΩ):114.34

Idle Current@8V(A): 0.8

No.of Cells(Lipo): 4S

ESC: 4S 29A

Max power(W): 457.92

Propeller: 5in Triblade

Max Current(A): 28.80

Hipot test@500V AC: PASS

Dynamic: ≤6mg

1450KV

KV: 1450KV

Stator Dimension(mm): 20

Stator Height(mm): 5

AWG: 24# 160mm Length

Motor Dimension(mm): Φ24.6×26.9

Weight Including Cable(g): 20.35

Magnet: N52H

Internal Resistance(mΩ):296.60

Idle Current@8V(A): 0.5

No.of Cells(Lipo): 6S

ESC: 6S 15A

Max power(W): 360.00

Propeller: 5in Triblade

Max Current(A): 15.00

Hipot test@500V AC: PASS

Dynamic: ≤6mg

Package Included:(Optional)

1x LA 2005 Ultralight Motor

SKU: BS047-012 Category:
Weight 0.5 kg
Dimensions 10 × 10 × 10 cm
Motor KV

1450kv, 2450kv, 2800kv, 3450kv
