AIKON F7 30X30 V2 HD FLIGHT CONTROLLER W/OSD

Availability:

In Stock


$58.00 $63.00

In Stock

The Aikon flight controller is a new generation flight controller designed specifically to work with the Aikon 4-in-1 ESCs. Aikon packed all the greatest features into one seamless flight experience.

Check out all our 30x30mm Flight Controllers and the rest of our Aikon Products!

FEATURES

  • 216mhz F7 processor
  • Onboard OSD and blackbox
  • Software controlled VTX power switch (assigned to USER1 mode by default)
  • LED and buzzer outputs (LED input doubles as PPM)
  • Quick connection cable for 4-in-1 ESCs
  • Quick connection cable for DJI HD system
  • On-board high overhead voltage regulators rated up to 6S (50v peak to handle voltage spikes)
  • USB Type C connector for easy programming

SPECIFICATIONS

  • Input Voltage: 2-6s
  • MCU: STM32F722
  • IMU: MPU6000 (interrupt pin connected) or BM!270
  • Blackbox: SPI 16MB
  • UARTS: 5
  • BEC: 10V 1.5A
  • Mounting Pattern: 30.5×30.5mm
  • Firmware: Betaflight
  • Target: AIKONF7
  • Weight: 12g

PACKAGE INCLUDES:

  • 1x Aikon F7 30×30 V2 Flight Controller w/OSD
